Chapter 4 Parameter Index
61
This page only for 3004GB/35R5PB and below
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P3.03
Multi-function
input selection
Terminal X3
0~40: Ibid
41: Command channel switch to
Keyboard control
42: Start PLC operation
43: Pause the PLC operating
44: Reset PLC stop status
45: Start Wobble frequency operating
46: Reset the Wobble frequency operating
status
47: Start PID operation
48: Reserved
49: Timing drive input
50: Counter trig signal input
51: Counter clear
52: Actual Length clear
53: Timing units chose
54:EH2 External fault rising edge valid
55: EH3 External fault falling edge valid
56~65: Reserved
37 × 0403
P3.04
Multi-function
input selection
Terminal X4
0~65: Ibid
66: PUL: Pulse input ( If have 2 signals
input, follow X4)
67: Single-phase speed measuring input
( If have 2 signals input, follow X4)
68: Speed measuring input SM1(only for
X4)
69: Speed measuring input SM2(only for
X5)
26 × 0404
P3.05
Multi-function
input selection
Terminal X5
27 × 0405
P3.06 Reserved Reserved 0 × 0406
P3.07 Reserved Reserved 0 × 0407
P3.08 Reserved Reserved 0 × 0408
P3.09
Operation mode
setup
0: 2-wire control mode1
1: 2-wire control mode 2
2: 3-wire control mode 1-self-hold
function (added any terminal of
X1-X5)
3: 3-wire control mode 2-self-hold
function (added any terminal of
X1-X5)
0 × 0409
