Alpha 6000 - Pb: MODBUS Communication; PC: Display Control

Chapter 4 Parameter Index
73
Function
code
Function Name Range of settings Default Change
MODBUS
Address
PA.03 No-load current I0 0.1~999.9A
This value
depends on
the inverter model.
× 0B03
PA.04 Resistance of stator %R1 0.00%~50.00%
This value depends on
the inverter model.
○ 0B04
PA.05 Leakage inductance %X 0.00%~50.00%
This value depends on
the inverter model.
○ 0B05
PA.06 Resistance of rotor %R2 0.00%~50.00%
This value depends on
the inverter model.
○ 0B06
PA.07 Mutual inductance %Xm 0.0%~200.0%
This value depends on
the inverter model.
○ 0B07
PA.08 Rated Speed 0~24000 rpm
This value depends on
the inverter model.
○ 0B08
PA.09 Reserved Reserved 0 - 0B09
Pb: MODBUS Communication
Function
code
Function Name Range of settings Default Change
MODBUS
Address
Pb.00
MODBUS Baud rate
selection
0: 1200 1: 2400
2: 4800 3: 9600
4: 19200 5: 38400
3 × 0C00
Pb.01
MODBUS slave
address
1~31 1 × 0C01
Pb.02
MODBUS parity
selection
0: Even parity
1: Odd parity
2: No parity
0 × 0C02
Pb.03
MODBUS time over
detection
0.0~100.0s
0: No time-out Setting
Others: Time-out detection time
0.0s ○ 0C03
Pb.04 Response delay time 0~500ms 5ms × 0C04
Pb.05
MODBUS frequency
reference unit
0: 0.01Hz
1: 0.1Hz
0 × 0C05
Pb.06
Selection of MODBUS
data storage
0: Not save to EEPROM
1: Directly save to EEPROM
0 × 0C06
Pb.07 CCF6 Fault Handling
0: Not generate fault and keep on
running
1: Generate fault and stop
0 × 0C07
Pb.08 Reserved Reserved 0 - 0C08
PC: Display Control
Function
code
Function Name Range of settings Default Change
MODBUS
Address
PC.00
LCD Language
selection
0: Chinese (Display Chinese
prompt in LCD screen)
1: English (Display English prompt
in LCD screen)
0 ○ 0D00
