Alpha 6000 - Pd: Protection and Fault Parameters

Chapter 4 Parameter Index
74
Function
code
Function Name Range of settings Default Change
MODBUS
Address
PC.01
Output frequency (Hz)
(before compensation)
0: No display 1: Display 1 ○ 0D01
PC.02
Output frequency (Hz)
(Actual)
0: No display 1: Display 0 ○ 0D02
PC.03 Output current(A) 0:No display; 1:Display 1 ○ 0D03
PC.04
Reference frequency
(Hz, flashes)
0:No display 1:Display 1 ○ 0D04
PC.05 Rotate speed (r/min) 0:No display 1:Display 0 ○ 0D05
PC.06
Reference speed
(r/min flashes)
0:No display 1:Display 0 ○ 0D06
PC.07 Linear speed (m/s) 0:No display 1:Display 0 ○ 0D07
PC.08
Reference line s peed
(m/s, flashes)
0:No display 1:Display 0 ○ 0D08
PC.09 Output power (kW) 0:No display; 1:Display 0 ○ 0D09
PC.10
Output torque (％)
0:No display; 1:Display 0 ○ 0D0A
PC.11 Output voltage (V) 0:No display 1:Display 1 ○ 0D0B
PC.12 Bus voltage (V) 0:No display 1:Display 0 ○ 0D0C
PC.13 AI1(V) 0:No display 1: Display 0 ○ 0D0D
PC.14 AI2(V) 0: No display 1: Display 0 ○ 0D0E
PC.15 Analog PID feedback 0: No display 1: Display 0 ○ 0D0F
PC.16 Analog PID feed 0: No display 1: Display 0 ○ 0D10
PC.17
External count value
(no unit)
0: No display 1: Display 0 ○ 0D11
PC.18
Terminal status (no
unit)
0:No display 1:Display 0 ○ 0D12
PC.19 Actual length 0: No display 1: Display 0 ○ 0D13
PC.20 Boot display choice 0~19 1 ○ 0D14
PC.21
Rotating speed display
coefficient
0.1~999.9%
Rotate speed = actual rotate
speed*PC.21(PG)
Rotate speed= 120*Operating
Frequency/PA.00*PC.21(non PG)
Reference speed =PID reference
speed*PC.21(PG)
Reference speed=
120*reference
frequency/PA.00*PC.21(non PG)
Note: This setting has no influence
to actual speed
100.0% ○ 0D15
