Chapter 1 Purchase Inspection
6
Chapter 1 Purchase Inspection
1.1 Unpacking Inspection
All inverters have passed the strict test before delivery. After unpacking, please check if
the product was damaged by careless transport, the product specification, model is
complied with the order, and if it has a quality check passed mark. If there is any problem,
please contact the supplier.
1.2 Naming Rule
The naming rule of the product is as following:
ALPHA6000 – 3 7R5 G B/ 3 011 P B - X
Series Code
S2: single phase 220V
Rated Voltage
2: three phase 220V
3: three phase 380V
R75: 0.75kW
Motor Power
7R5: 7.5kW
075: 75kW
G: General
Application
P: Square torque load
B: With Brake
Additional Description
Additional Description
□:Narrow-body type
Y: Standard type
(Wall-mounted)
X:Standard type(with
base)
ALPHA6000
ALPHA6100
Note: 1. If the user has special needs, please specify the technical requirements in
the order.
2. X rule applies to 160-500kW models.
