Alpha 6000 - P4: Analog and Pulse Function Parameters

Chapter 4 Parameter Index
65
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P3.15
Reserved
(3004GB/35R5PB
or below)
0~27: Ibid
28: Fixed-length arrived, output a high
level signals
29: Standby
30: Zero-speed running
Note: Function code
P3.14 and P3.15 can’t
be set, and the output functions of 26
are reserved
0 -
040F
Terminal Y2
function definition
(35R5GB/37R5PB
or above)
2 ×
P3.16
Output functions
selection of relay 1
(TA/TB/TC)
19 × 0410
P3.17
Fixed length
reaches the
terminal output
hold time
(3004GB/35R5PB
or below)
0.0~3.0s 1.0s
× 0411
Output functions
selection of relay 2
(BRA/BRB/BRC)
(35R5GB/37R5PB
or above)
0~30:the same as P3.16 0
P3.18
FAR detection
width
0.00~10.00Hz 2.50Hz ○ 0412
P3.19
Frequency
detection threshold
(FDT level)
3004GB/35R5PB or below :
0.00~650.0Hz
35R5GB/37R5PB or above:
0.00~400.0Hz
50.00Hz ○ 0413
P3.20
Frequency
detection
hysteresis values
(FDT lag)
0.00~10.00Hz 1.00Hz ○ 0414
P3.21
Frequency upper
limit arriving
output delay time
0.0~100.0s 0.0s ○ 0415
P3.22
Frequency lower
limit arriving
output delay time
0.0~100.0s 0.0s ○ 0416
P3.23
Torque detection
reference
0.0~200.0% 100.0% ○ 0417
P3.24 Preset Count value 0~9999 0 ○ 0418
P3.25
Preset Timing
arriving
0.0~6553.0s 0.0s ○ 0419
P3.26
Preset operating
time
0~65530h 65530h × 041A
