Chapter 4 Parameter Index
64
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P3.10
Terminal UP/DN
rate
0.01~99.99Hz/s
1.00Hz
/s
○ 040A
P3.11
UP/DN reference
amplitude
0.00~Frequency upper limit 10.00Hz × 040B
P3.12
Digital frequency
UP/DOWN save
selection
0: Receive STOP, UP/DN reference
reset to zero
1: Receive STOP, UP/DN reference not
reset to zero, and not save when
power loss
2: Receive STOP, UP/DN reference not
reset to zero, and save when power
loss; If P0.01is set to 1, P0.00 will be
saved when power loss.
2 × 040C
P3.13
Define Functions
of terminal DO
0: NULL
1: RUN
2: FAR: Frequency arriving
3: FDT: Frequency detection threshold
4: FDTH: Frequency upper limit
arriving
5: FDTL: Frequency lower limit
arriving
6: Upper and lower limits of Wobble
frequency
7: Zero-speed running
8: Completion of simple PLC
operation
9: PLC cycle completion
indication
10: Inverter ready (RDY)
11: Coast-to-stop
12: Auto restart
13: Timing Arriving
14: Counting value arriving output
15: Preset operating time arriving out
16: Torque arriving detection threshold
17: CL: Current Limit
18: Over-voltage stall
19: Inverter fails
20: External fault stop (EXT)
21: Uu1: Under
voltage lock-up
22: Reserved
23: OLP: Overload signal
24: Analog signals 1 abnormal
25: Analog signals 2 abnormal
26: STEP: Programming Running
steps (only active to DO\Y1\Y2,
and need to set P3.13, P3.14, P3.15
the same value as 26)
27: Fault type output (Only active to
DO\Y1\Y2, and need to set P3.13,
P3.14, P3.15 the same value as 27)
0 × 040D
P3.14
Reserved(3004GB
/35R5PB or
below)
0 -
040E
Terminal Y1
function
definition(35R5G
B/37R5PB or
above)
1 ×
