Alpha 6000 - P2: Auxiliary Operation Parameters

Chapter 4 Parameter Index
57
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P1.07
Time of S-curve
rising
10.0~80.0% (Acc/Dec Time)
P1.06+P1.07≤90%
60.0% ○ 0207
P1.08 Stop mode
0: Deceleration to stop
1: Coast to stop
2: Dec +DC braking
0 × 0208
P1.09
DC injection
braking frequency
at stop
0.00~MIN(50.00Hz, Frequency upper
limit)
0.00Hz ○ 0209
P1.10
DC injection
braking waiting
time at stop
0.00~10.00s 0.00s ○ 020A
P1.11
DC braking
current at stop
This value depends on the inverter
model
Type G: 0.0~100.0% (inverter rated
current)
Type P: 0.0~80.0% (inverter rated
current)
0.0% ○ 020B
P1.12
DC braking time at
stop
0.0~30.0s 0.0s ○ 020C
P1.13
Dynamic braking
selection
0: Dynamic braking is disabled
1: Dynamic braking is enabled
2：Magnetic flux braking enabled
3：Both enabled
1 × 020D
P1.14
Brake voltage
level setting
(3004GB
/35R5PB or
below)
360~750V
1AC:
380V
3AC:
700V
× 020E
Brake utility rate
(35R5GB/37R5PB
or above)
0.0~100.0%
Note: Build-in is active only for the
model of inverter of 15kW or below of
this series,
Dynamic braking takes effect
automatically during deceleration
100.0%
P1.15 Trip-free treatment
0: once trip-free, report Uu1 fault
1: In trip-free time give
Uu alarm, otherwise
report Uu1 fault
2: once trip-free, give
Uu alarm
0 × 020B
P1.16 Trip-free time 0.5~10.0s
This
value
depends
on the
inverter
model.
× 0210
