Chapter 5 Parameter Introductions
148
If PC.09 is set to 1, output power will be displayed with unit “kW” in monitoring
state, and all unit indicators will be off. If it is set to 0, output power will not be
displayed.
PC.10 Output torque (％) Range: 0,1【0】
0: No display 1: Display
Note:
If PC.10 is set to 1, output torque will be displayed with unit “%” in monitoring
state. If PC.10 is set to 0, output torque will not be displayed.
PC.11 Output voltage (V)
Range: 0,1【0】
PC.12 Bus voltage (V)
Range: 0,1【0】
0: No display 1: Display
Note:
If PC.11 is set to 1, output voltage will be displayed in monitoring state, and the unit
indicator “V” will be lit up. If it is set to 0, output voltage will not be displayed.
If PC.12 is set to 1, bus voltage will be displayed in monitoring state, and the unit
indicator “V” will be lit up. If it is set to 0, bus voltage will not be displayed.
PC.13 AI1(V)
Range: 0,1【0】
PC.14 AI2(V)
Range: 0,1【0】
0: No display 1: Display
Note:
If PC.13 is set to 1, analog input voltage AI1 will be displayed in monitoring state,
and the unit indicator “V” will be lit up . If it is set to 0, analog input voltage AI1
will not be displayed.
If PC.14 is set to 1, analog input voltage AI2 will be displayed in monitoring state,
and the unit indicator “V” will be lit up. If it is set to 0, analog input voltage AI2
will not be displayed.
PC.15 Analog PID feedback (no unit)
Range: 0,1【0】
PC.16 Analog PID feed (no unit)
Range: 0,1【0】
0: No display 1: Display
Note:
Analog PID feedback/ feed is the Product of “percentage of physical value
corresponding to analog value” and “Analog closed loop measuring range”.
If PC.15 is set to 1, analog PID feedback will be displayed in monitoring state, and
all unit indicators will be lit up. If it is set to 0, analog PID feedback will not be
displayed.
If PC.16 is set to 1, analog PID feed will be displayed in monitoring state, and all
unit indicators will lit up and flickered. If P7.00 is set to 0 and P7.01 is not set to 9,
