Chapter 2 Installation and Wiring
18
 Function of Control Circuit Terminals
Table 2-8 Function of control circuit terminals
Category Terminal Name Functions Specification
Analog input
AI1 Analog input1
Receive voltage/current
input. Voltage or current
input mode are
selectable by
data-chosen-switch
SW1. Voltage input
mode is the default
mode, refer to
P4.00~P4.10 to set the
range.(The reference
ground is GND)
Input voltage range:
0~10 V
(Input resistance:
100 kΩ)
Input current range:
0~20 mA
(Input resistance:
500Ω)
AI2 Analog input2
Analog output
AO1
Analog
output1
Provide analog voltage
/current output(total 12
kinds of signals).
Voltage or current
output mode are
selectable by switch
SW2. Voltage output
mode is the default
mode. Refer to P4.17 for
details. (The reference
ground is GND)
Output current range:
0/4~20 mA
Output voltage range:
0/2~10 V
AO2
Analog
output2
(only
35R5GB/37R5
PB~3500G)
Provide analog voltage
/current output (total 12
kinds of signals).
Voltage or current output
mode are selectable by
switch SW3. Voltage
output mode is the
default mode. Refer to
P4.18 for details. (The
reference ground is
GND)
