Chapter 4 Parameter Index
71
Function
code
Function Name Range of settings Default Change
MODBUS
Address
P7.01
PID feedback
selection
0: AI1 terminal
1: AI2 terminal
2: Serial communication
3: Pulse feedback
4: |AI1-AI2|
5: Reserved
6: AI1+AI2
7: MIN (AI1, AI2)
8: MAX (AI1, AI2)
9: PG or single-phase speed measuring
input
1 × 0801
P7.02
Analog PID digital
feed
0.0~P7.14 0.0 ○ 0802
P7.03 Speed PID feed 0~24000rpm 0rpm ○ 0803
P7.04
PID direction
alteration
permission
0:Not allowed
1:Allowed
0 × 0804
P7.05
PID proportional
gain (KP)
0.1~9.9 1.0
○ 0805
P7.06
PID integration
time
0.00~100.0s 10.00s ○ 0806
P7.07
PID differential
time
0.00~1.00s 0.00s ○ 0807
P7.08
PID delay time
constant
0.00~25.00s 0.00s
○ 0808
P7.09 Residual margin 0.0~999.9 0.2
○ 0809
P7.10
PID adjust
characteristic
0: Positive
1: Negative
0
× 080A
P7.11
Integration adjust
selection
0: Stop Integration Adjust when
frequency arrive at limit;
1: Continue Integration Adjust when
frequency arrive at limit
0
× 080B
P7.12
PID preset
frequency
3004GB/35R5PB or below:
0.00~650.0Hz
35R5GB/37R5PB or above:
0.00~400.0Hz
0.00Hz ○ 080C
P7.13
Hold time of PID
preset frequency
0.0~3600s 0.0s
× 080D
P7.14
Analog closed
loop measuring
range
Max[P7.02,1.0]~999.9 100.0 ○ 080E
P7.15 Enable dormancy 0: Disable 1: Enable 0 × 080F
P7.16 Dormancy delay 0~999s 120s ○ 0810
P7.17
Dormancy
threshold
0~Frequency upper limit
20.00Hz
○ 0811
P7.18
Awakening
threshold
0.0~999.9 3.0 ○ 0812
P7.19
PID amplitude
modulation
coefficient
0:1*(P2.11)
1:(Frequency setting 2 /
P0.07)*(P2.11)
0 × 0813
