Chapter 5 Parameter Introductions
81
Terminal control: The user should define X1~X8 terminal to achieve RUN, F/R,
FWD, REV, HLD and other running functions (see P3.01~P3.08) first, and then
used the terminals to control the inverter Start, Stop. etc.
Serial communication: Users connected the serial communication port to PC or
PLC, then through communication to control the inverter Start, Stop, F/R and so on.
Note 2:
If the “STOP/RESET” key is valid, users can stop inverter by pressing
“STOP/RESET” key on the keyboard for emergency stop. If the “STOP/RESET”
key is invalid, the user can only stop the inverter by preset control mode.
If P0.04 is set to 5, the JOG key is invalid. If the JOG key is invalid, the user can
only start Jog operation by FJOG or RJOG terminal.
In Keyboard and Terminal control mode, communications read and write
commands will be ignore.
P0.05 Keyboard direction setting
Range: 0,1【0】
0: Forward 1: Reverse
Note:
Pressing “FWD/REV” will switch the direction, and change the value of this
parameter P0.05. But the changed direction only take effect currently.
Only by changing value of function code and pressing “ENTER” to save the value,
keyboard direction setting will be saved permanently.
Direction priority: Terminal set is the highest, second is set by communication,
keyboard is the lowest. If the high one is invalid, the lower priority will take effect.
P0.06 Basic Frequency
Range:
S2R4GB~3004GB/35R5PB：
0.10~650.0Hz【50.00Hz】
35R5GB/37R5PB and above: 0.10~400.0Hz【50.00Hz】
P0.07 Max output frequency
Range:
S2R4GB~3004GB/35R5PB：
MAX [50.00Hz, Frequency upper limit, Reference
frequency] ~650.0Hz【50.00Hz】
35R5GB/37R5PB and above:
MAX [50.00Hz, Frequency upper limit, Reference
frequency] ~400.0Hz【50.00Hz】
P0.08 Frequency upper limit
Range: MAX[Frequency lower limit, Jog frequency,
UP/DN reference amplitude ,Dormancy
threshold]~Max frequency【50.00Hz】
P0.09 Frequency lower limit
Range: 0.00~Frequency upper limit【0.00Hz】
