Chapter 5 Parameter Introductions
97
P2.11 Multi-step frequency 1
Range: 0.00~Max frequency【5.00Hz】
P2.12 Multi-step frequency 2
Range: 0.00~Max frequency【0.00Hz】
P2.13 Multi-step frequency 3
Range: 0.00~Max frequency【0.00Hz】
P2.14 Multi-step frequency 4
Range: 0.00~Max frequency【0.00Hz】
P2.15 Multi-step frequency 5
Range: 0.00~Max frequency【0.00Hz】
P2.16 Multi-step frequency 6
Range: 0.00~Max frequency【0.00Hz】
P2.17 Multi-step frequency 7
Range: 0.00~Max frequency【0.00Hz】
P2.18 Multi-step frequency8
Range: 0.00~Max frequency【0.00Hz】
P2.19 Multi-step frequency 9
Range: 0.00~Max frequency【0.00Hz】
P2.20 Multi-step frequency10
Range: 0.00~Max frequency【0.00Hz】
P2.21 Multi-step frequency 11
Range: 0.00~Max frequency【0.00Hz】
P2.22Multi-step frequency 12
Range: 0.00~Max frequency【0.00Hz】
P2.23 Multi-step frequency 13
Range: 0.00~Max frequency【0.00Hz】
P2.24 Multi-step frequency 14
Range: 0.00~Max frequency【0.00Hz】
P2.25Multi-step frequency 15
Range: 0.00~Max frequency【0.00Hz】
Note:
Define Multi-step frequency respectively, which can be used in Multi-step speed
running and simple PLC running.
When frequency setting type is combined frequency (P0.03>1) and frequency
setting 1 is closed loop PID(P0.01=9), P2.11 is used to define the analog PID’s
adjustment, actual range is【-P2.11~P2.11】in Hertz.
P2.26 Acc time 2
Range: 0.1~3600s【6.0/20.0s】
P2.27 Dec time 2
Range: 0.1~3600s【6.0/20.0s】
P2.28 Acc time 3
Range: 0.1~3600s【6.0/20.0s】
P2.29 Dec time 3
Range: 0.1~3600s【6.0/20.0s】
P2.30 Acc time 4
Range: 0.1~3600s【6.0/20.0s】
P2.31 Dec time 4
Range: 0.1~3600s【6.0/20.0s】
Note:
Define Acc/Dec time 2, 3 and 4 respectively (Acc/Dec time 1 is defined in P0.21
and P0.22). Acc/Dec time 1, 2, 3 and 4 can be selected through external terminals,
set by P3.01~P3.08. If all terminals related with Acc/Dec time are invalid, the
