Settings
6. Open the injector sluice flap (Fig. 124/1) on
all seed dosing units.
Fig.
124
CAUTION
Risk of contusions on opening
and closing the injector sluice
flap (
Fig. 124/1)!
Hold the injector sluice flap only
by the lug (
Fig. 124/2), otherwise
there is a danger of injury when
the spring
-loaded injector sluice
flap snaps closed.
Never insert your hand between
the injector sluice flap and the
injector sluice!
1. Adjust the desired sowing rate in the AMATRON 3.
1.1 Open the menu "Job".
1.2 Select the job number.
1.3 Enter the job name (optional).
1.4 Enter job notes (optional).
1.5 Enter the seed type.
1.6 Enter the 1000
grain weight (required only with a grain meter).
1.7 Enter the desired sowing rate.
1.8 Start the job (press the "Start job" button).
1.9 Adjust the sowing rate with calibration test as described in
the operation manual AMATRON 3 (see section "Calibrat-
ing machines with electr. full dosing").
The number of engine revolutions for the calibration test until the
signal tone sounds is governed by the sowing rate:
0 to 14.9 kg → Engine revolutions to 1/10 ha
15 to 29.9 kg → Engine revolutions to 1/20 ha
from 30 kg → Engine revolutions to 1/40 ha.
2. Secure the calibration troughs on the seed hopper.
3. Close the injector sluice flaps with special care (see danger no-
tice [Fig. 124]).
Cirrus BAH0049-1 09.14
121
