Product description
4 Product description
This section:
• Provides a comprehensive overview of the machine structure.
• Provides the names of the individual modules and controls.
Read this section when actually at the machine. This helps you to
understand the machine better.
Main assemblies of the machine
Fig. 20
Fig. 20/…
(1) Seed hopper
(2) Central dosing
(3) Blower fan
(4) Seed distributor head
(5) RoTeC+ Coulter
(6) Two-row disc array
(7) Tapered tyres with integrated running gear
(8) Roller harrow
(9) Track marker
44 Cirrus BAH0049-1 09.14
