10. Set the track discs so that they mark the
tramline created by the tramline coulters.
11. Adapt the work intensity to the soil by turn-
ing the discs (position the discs on light
soils roughly parallel to the direction of
travel and on heavy soils more on in a for-
ward position).
12. Tighten the screws (Fig. 145/1) firmly.
Fig. 145
When working with tramline rhythm 2 and tramline rhythm 6 plus fit
only one of the two track marker discs.
The track width of the cultivation tractor is then scored on the field on
a back and forth run.
8.11.3 Set the track disc carrier to transport position
Move the track disc carriers in reverse sequence (as described
above) into the transport position.
During transport, store the track discs (Fig. 144/4) in a suitable stow-
ing space.
Cirrus BAH0049-1 09.14
139
