Structure and function
Tramline rhythm
Seed drill working width
3.0 m 4.0 m 6.0m
Tramline spacing
(working width of the fertiliser spreader and field sprayer)
1
12 m
3
9 m 12 m 18 m
4
12 m 16 m 24 m
5
15 m 20 m 30m
6
18 m 24 m 36 m
7
21 m 28 m 42m
8
24 m 32 m
9
36 m
2 plus
12 m 16 m 24 m
6 plus
18 m 24 m 36 m
Fig. 94
5.19.1 Examples for creating tramlines
The creation of tramlines is shown in Figure (Fig. 95) using various
examples:
A = Working width of the seed drill
B = Tramline spacing
(= working width of fertiliser spreader / field sprayer)
C = Tramline rhythm (input on the AMATRON 3)
D = Tramline counter (during work the field runs are number con-
secutively and displayed on the AMATRON 3).
Perform any inputs and outputs with the aid of the AMATRON 3 oper-
ating manual.
Example:
Working width of seed drill: ... 6 m
Working width, fertiliser
spreader/field sprayer: ........... 18m = 18m tramline spacing
1. In the adjacent table (Fig. 95) look for the following:
in column A the seed drill's working width (6 m) and
in column B the tramline spacing (18 m).
2. On the same line in column "C" take the reading for the tramline
rhythm (tramline rhythm 3) and set this on the AMATRON 3.
3. On the same line in column "D" under the inscription "START"
take the reading of the tramline counter for the first field run
(tramline counter 2) and enter this figure on the AMATRON 3.
Input this value directly before commencing the first field trip.
88 Cirrus BAH0049-1 09.14
