4.8 Technical data
Cirrus
3002 4002 6002
Working width [m] 3.0 4.0 6.0
Total length
[m] 7,59 8,09 8,09
Fill level
without extension
[m]
2350 2350 2500
with extension 2540 2540 2690
Hopper vol-
ume
without extension
[l]
2200 2200 3000
with extension 2800 2800 3600
Full load (on
field)
without extension
[kg]
1800 1800 2400
with extension 2300 2300 2900
Number of
sowing units / Row spacing [cm]
24 / 12,5 32 / 12,5 48 / 12,5
18 / 16,0 24 / 16,0 36 / 16,0
Continuous acoustic pressure level [dB(A)] 74 74 74
Working speed [km/h] 12 to 16 12 to 16 12 to 16
Power requirement (from) [kW/bhp] 90/120 110/150 147/200
Oil flow rate (minimum). [l/min] 80 80 80
Max. hydraulic working pressure [bar] 210 210 210
Coupling point category Category III III III
Number of tapered ring tyres 6 8 12
Maximum
drawbar load
with full seed
hopper
(on the field)
without extension
[kg]
2200 2500 2800
with extension 2500 2800 3100
Transport running gear Integrated with 4 running wheels
Transmission/hydraulic fluid Transmission/hydraulic fluid Utto SAE 80W API GL4
Electrical system [V] 12 (7-pin)
Service brake system
(connection to tractor)
Dual-circuit pneumatic braking system or
hydraulic braking system
2)
Effective brake in the integrated
running gear
Hydraulically acting
1)
with exact harrow, without tramline marker
2)
Not allowed in Germany and in several other countries.
Cirrus BAH0049-1 09.14
55
