Structure and function
5.10 Distributor head
In the distributor head (Fig. 74/1) the seed is
distributed uniformly over all the seed coulters.
The number of distributor heads depends on the
machine working width. A seed doser always
supplies one distributor head.
Fig.
74
5.11 Radar
The radar measures the distance covered.
AMATRON 3 uses this data to determine
• the travel speed
• the worked area (hectare counter)
• the speed of the electric motor that drives
the dosing roller.
Fig.
75
78 Cirrus BAH0049-1 09.14
