Cleaning, maintenance and repairs
12.6.1.2 Adjusting the track width of the cultivating tractor (specialist workshop)
When the machine is delivered or when buying a
new tractor, check that the tramline is set to the
track width (
Fig. 216/a) of the tractor.
216
The track changes with the number of coulters not outputting seed
when the tramlines are created.
To create two tracks, in the distributor head it is possible to close the
sliders (Fig. 215/2):
• for machines, Cirrus 3002/4002-2 up to 3 openings
• for machines, Cirrus 6002 up to 6 openings
Deactivate any non-required sliders (Fig. 215/2). Deactivated sliders
do not close the feed lines to the tramline coulters.
Always activate or deactivate pairs of sliders positioned opposite each
other on the base plate.
Cirrus BAH0049-1 09.14
199
