Cleaning, maintenance and repairs
12.6 Workshop settings and repair work
12.6.1 Adjusting the wheelmark spacing / track width (specialist workshop)
WARNING
The distributor head is located at the centre of the machine.
Apply the tractor parking brake, switch off the tractor engine and
remove the ignition key.
Before approaching, clean the path to the distributor head and
the area of the distributor head (danger of slippage).
There is the risk of an accident on the path to the distributor
head and in the area of the distributor head.
12.6.1.1 Adjusting the wheelmark spacing of the cultivating tractor (specialist workshop)
When the machine is delivered or when buying a
new tractor, check that the tramline is set to the
wheel mark spacing (
Fig. 214/a) of the tractor.
214
The seed line tubes (Fig. 215/1) of the tramline
coulters must be fixed to the distributor head
openings, which can be closed by the sliders
(
Fig. 215/2).
If necessary, interchange the seed line tubes.
Fig. 215
Set the track discs of the tramline marker (if present) to the new track.
198 Cirrus BAH0049-1 09.14
