Cleaning, maintenance and repairs
12.4.2 Lubrication point overview
Number of lubrication nipples
Lubrication in-
terval
Cirrus 3002 Cirrus 4002 Cirrus 6002
Fig. 200/1 1 1 1 25 h
Fig. 200/2 1 1 1 25 h
Fig. 201/1 2 2 2 25 h
Fig. 201/2 2 2 2 25 h
Fig. 202/1 ― 2 2 25 h
Fig. 203/1 ― 2
1)
4
1)
25 h
Fig. 203/2 ― 2
1)
4
1)
25 h
Fig. 203/3 ― 4
1)
4
1)
25 h
Fig. 204/1 2 2
1)
2
1)
25 h
Fig. 204/2 2 2
1)
2
1)
25 h
Fig. 204/3 2 2
1)
2
1)
25 h
Fig. 204/4 2 2
1)
2
1)
―
2)
Fig. 204/5 2 2
1)
2
1)
―
2)
Fig. 204/6 ― 2
1)
2
1)
25 h
1)
Lubricate only with folded in, raised and secured machine (see sec-
tion 0).
2)
regular lubrication not necessary.
Fig. 199
Cirrus BAH0049-1 09.14
181
