Coupling and uncoupling the machine
7.2 Uncoupling the machine
WARNING
Risk of contusions, cutting, catching, drawing in and knocks
through insufficient stability and possible tilting of the uncou-
pled machine!
Set the empty machine down on a horizontal parking area with a firm
base.
When uncoupling the machine, there must always be enough space
in front of the machine, so that you can align the tractor with the ma-
chine if necessary.
1. Align the tractor and machine straight and
park the empty machine on a horizontal
parking surface with a firm base.
2. Retract the integrated running gear (lower
the machine). Here the machine can be
coupled or uncoupled.
3. Press the button (switch off Fig. 108/1)
(AMATRON 3).
4. Apply the tractor parking brake, switch off
the tractor engine and remove the ignition
key.
108
5. Release the spring pins (Fig. 109/1) and
remove the 4 wheel chocks from the mount-
ings at the front of the machine.
109
Cirrus BAH0049-1 09.14
