Product description
4.1 Overview of subassemblies
Fig. 21/...
AMATRON 3 operator terminal
Fig.
21
Fig. 22/...
(1) Radar
(2) Wheel chocks
Fig.
22
Fig. 23/...
(1) Electrohydraulic control blocks
(2) Hydraulic accumulator with nitrogen filling
for pretensioning the outswung machine ex-
tension arms
Fig.
23
Fig. 24/...
(1) Draw rail
(2) Sustainer, extendable
Fig.
24
