Product description
Fig. 25/...
(1) Mounting for supply lines
(2) Roller holder for stowing
ο of the operating manual
ο of the dosing rollers
ο of the digital scales.
Fig.
25
Fig. 26/...
(1) Loading board with ladder
(2) Holding point
Fig.
26
Fig. 27/...
(1) Swivel cover
(2) Cover hook
Fig.
27
Fig. 28/...
(1) Crank for exact harrow adjustment
(2) Seed doser
(3) Electric motor
(when fitting the "full dosing", in each case,
an electric motor powers a seed dosing
unit)
(4) Injector housing
(5) Calibration trough
(in mounting for calibration test)
Fig.
28
46 Cirrus BAH0049-1 09.14
