11.2 Failure of the AMATRON 3 during work
If the Amatron
+
fails when work is in progress on the field, it will not be
possible to continue the sowing operation. If it is not possible to elimi-
nate the fault on-site, the machine can be folded in, moved into the
road transport position and transported to the nearest workshop.
Transporting the machine to the nearest workshop after failure of the AMATRON 3
DANGER
Actuate the tractor's control units only in the tractor cab.
Before actuating the tractor's control units, direct any peo-
ple out of the danger area.
1. Apply the tractor parking brake, switch off
the tractor engine and remove the ignition
key.
2. Take the two valve pins (Fig. 190/1) out
of the valves and turn them through 45
degrees to lock.
Fig. 190
DANGER
Only if the AMATRON 3 fails, fold the machine in emergency
mode.
After folding in the booms, check whether the locking hooks
(Fig. 183/1) lock the booms.
172 Cirrus BAH0049-1 09.14
