Example
Values adjustable in the AMATRON 3
Probable
working speed: ............................ 10 km/h
Starting speed: ............................ 50 %
Time to achieve working speed: .... 8 seconds
Fig. 69
5.8.4 Increasing sowing rate, coulter pressure and harrow pressure
The sowing rate is increased during the work by entry in the AMA-
TRON 3.
If the coulter pressure and harrow pressure are also to be increased,
the coulter pressure button
in the AMATRON 3 must be select-
ed. Actuating the control valve 2 then increases the coulter pressure
and the harrow pressure. Individual functions can be cut out by reposi-
tioning the pins.
It is necessary to equip the machine with
• the hydr. coulter pressure adjustment
• the hydr. exact harrow pressure adjustment.
74 Cirrus BAH0049-1 09.14
