Settings
8.2 Inserting dosing roller in metering unit
1. Remove the clip pin (Fig. 118/2)
(only necessary when the seed hopper is
full to seal the hopper with the slider (
Fig.
118/1).
Fig.
118
The
dosing rollers can be replaced
more easily, if the seed hopper is
empty.
2. Push the slider (Fig. 119/1) into the dosing
unit up to the stop.
→ The slider seals the seed hopper. Seed
cannot pour out inadvertently when the dos-
ing roller is replaced.
Fig.
119
118 Cirrus BAH0049-1 09.14
