Amazone Cirrus Series User Manual

Cleaning, maintenance and repairs
12.7 Lower link pin
WARNING
Risk of contusions, catching, and knocks when the machine
unexpectedly releases from the tractor!
Check the lower link pin for conspicuous defects whenever the ma-
chine is coupled. Replace the draw bar, if there are any clear signs of
wear to the lower link pin.
12.8 Bolt tightening torques
Thread
Width across
flats
[mm]
Tightening torques [Nm]
as a function of the bolt/nut grade
8.8 10.9 12.9
M 8
13
25
35
41
M 8x1
27
38
41
M 10
16 (17)
49
69
83
M 10x1
52
73
88
M 12
18 (19)
86
120
145
M 12x1.5
90
125
150
M 14
22
135
190
230
M 14x1.5
150
210
250
M 16
24
210
300
355
M 16x1.5
225
315
380
M 18
27
290
405
485
M 18x1.5
325
460
550
M 20
30
410
580
690
M 20x1.5
460
640
770
M 22
32
550
780
930
M 22x1.5
610
860
1050
M 24
36
710
1000
1200
M 24x2
780
1100
1300
M 27
41
1050
1500
1800
M 27x2
1150
1600
1950
M 30
46
1450
2000
2400
M 30x2
1600
2250
2700
For the tightening torques of the wheel and hub bolts, see section
Retighten wheel and hub screws, Seite 186.
204 Cirrus BAH0049-1 09.14
