The tramline selection allows the creation of tramlines at preselected
intervals on the field.
Tramlines are seed-free tracks (Fig. 93/A) for fertilising and plant care
machines used later.
The tramline spacing (Fig. 93/b) corresponds to the working width of
the care machines (Fig. 93/B), e.g. fertiliser spread and/or sprayer,
which are used on sown fields.
Fig. 93
To set the different tramline spacings (Fig. 93/b), appropriate tramline
rhythms must be entered on the AMATRON 3.
The figure (Fig. 93) shows the tramline rhythm 3. During the work the
field runs are numbered consecutively (tramline counter) and dis-
played in the AMATRON 3.
In tramline rhythm 3, the tramline counter shows the field runs in the
following order: 2-0-1-2-0-1-2-0-1…etc.
Upon creating a tramline the tramline counter indicates the number
"0" on the AMATRON 3.
The required tramline rhythm (see table Fig. 94) is derived from the
required tramline spacing and the working width of the seed drill. Fur-
ther tramline rhythms can be seen in the AMATRON 3 operating
manual.
The wheelmark spacing (Fig. 93/a) of the tramline corresponds to that
of the cultivating tractor and is adjustable.
The track width (Fig. 93
/c) of the tramline increases with an increasing
number of tramline coulters fitted next to each other.
Cirrus BAH0049-1 09.14
87
