GreenDrill control terminal 5.2
GreenDrill BAH0054-9 11.17
89
Fault Possible fault elimination
Seeding shaft rotates
in transport position
 Change the lifting unit signal
(see section 0, page 102)
Seeding shaft does not rotate
in working position
 Switch on the seeding shaft and start driving
 Check the speed signal
 Change the lifting unit signal
(see section "Entry of the working position sensor signal
source", page 102)
Low level sensor
without alarm message
 Check the plug and cable
 Change the intensity of the sensor
(see section 7.15, page 83).
Low level sensor
with continuous alarm
 Realign the low level sensor
 Change the intensity of the sensor
(see section 7.15, page 83)
Speed signal
is missing
 Check the settings for the speed sensor
(see section 7.20, page 99)
 Check the labels and connections
of the splitter
 Test whether the speed signal is received on the control ter-
minal, if the speed sensor is not connected to the splitter but
rather to the control terminal.
If signals are received, replace the defective splitter.
Lifting unit signal
is missing
 Check whether the sensor and magnets are opposite to each
other in the end position
 Check the sensor settings (see section 7.20, page 99)
 Check the connections and labels on the splitter
 Test whether the lifting unit signal is received on the control
terminal, if the lifting unit signal sensor is not connected to the
splitter but rather to the control terminal.
If signals are received, replace the defective splitter.
The control terminal cannot
be switched on
 Check the plug and power cable
 Check the fuse
 Check the battery
 Check the connections of the battery cable (if equipped) (see
section 7.18.3.2,
page 92).
The control terminal is
switched off when the blower
fan or seeding shaft motor is
switched on
 Check the battery voltage
 Check the contacts
 Power cable plug
 Implement cable plug
