The NetLinx Studio v2.4 Work Area

etLinx Studio (v2.4 or higher)

 The fourth level contains all of the actual files that make up the System (.AXS, .AXI,

.TPD, .TKO, .TP4 .IRL/.IRV, and *.*).

 The fifth and final level indicates the file mapping information for each file, as applicable.

Click on the "+" folder flags to expand the folders to expose any subfolders; click the "-" folder

flags to collapse the folders.

The hierarchical file structure of the Workspace tab is described below:

Workspace Folder

 You can have one Workspace open at a time. A Workspace contains at least one Project,

and each Project contains at least one System.

 Right-mouse click anywhere within the workspace tab to open the Workspace context

menu.

Project Folders

 Right-mouse click on any Project folder to open the Project Folder context menu.

 Expand any Project folder to display the System folder(s) contained in that Project.

System Folders

 Each System has it's own platform (Axcess or NetLinx) setting along with the

communication information (i.e. IP address or COM port setting with the appropriate

baud rate, etc.).

 Right-mouse click on any System folder to open the System Folder context menu.

The 'Module' folder only appears if NetLinx is designated as the system platform (via

the Communication Settings dialog).

FIG. 5 Workspace Window - Workspace Tab
