Working With Systems and System Files
46
NetLinx Studio (v2.4 or higher)
Creating New System Files
Use the File > New command (or toolbar button) to create all types of System files, including
Source Code, Include, Block and Text files. This command creates a new file, but does not
automatically associate the new file with any Project or System.
To create new System file:
1. Select New from the File menu, or click the toolbar button to open the New dialog.
2. Select the type of file that you want to create (Source File, Include File, Block File, or Standard
Text).
3. Click OK to open an empty Source Code Editor window.
4. Develop the file as needed in the Source Code Editor window, and select File > Save (or click
the toolbar button).
5. Specify a name and target location for the new file in the Save As dialog.
File Types And Extensions
Use the Project > Add File To System command to add the file to a System.
The Workspace Wizard option launches the Workspace Wizard, which steps you
through the process of creating a new Workspace with a Project and one System.
File Type File Extension
Axcess Source Code File .AXS
Include File .AXI
Compiled Axcess Source Code File .TOK
Compiled NetLinx Source Code File .TKN
NetLinx Source Code File .SRC
Block File .AXB
TPDesign3 User Interface File .TPD
TPDesign4 User Interface File .TP4
KPDesign Keypad Touch File .KPD
IR Library File .IRL
IRV File .IRV
IRN (IR Database) File .IRN
Standard Text File .TXT
Other File .* (any other extension)
