VNA Master

User Guide

MS2024A/MS2026A and

MS2034A/MS2036A

Vector Network Analyzer

2 MHz to 6 GHz

Spectrum Analyzer

9 kHz to 7.1 GHz

TM

C

M

Y

CM

MY

CY

CMY

K

00986-00110B_Option.pdf 11/6/2007 2:27:42 PM

Table of Contents

Default Chapter11
- Safety Symbols11
- Table of Contents13
Chapter 1 - General Information23
- Introduction23
- Identifying the Models24
- Description25
- MS2024A Options26
- MS2026A Options27
- MS2034A Options27
- MS2036A Options27
- Standard and Optional Accessories28
- Soft Carrying Cases and Tilt Bails33
  - VNA Master Soft Carrying Case33
  - VNA Master Tilt Bail Stand35
- Preventive Maintenance36
- Calibration Requirements - Vector Network Analyzer36
- Calibration Requirements - Spectrum Analyzer36
- Annual Verification36
- ESD Cautions37
- Battery Replacement37
Chapter 2 - Quick Start Guide39
- Introduction39
- Turning the VNA Master on for the First Time39
- Front Panel Overview40
- Typical Vector Network Analyzer Display42
- Typical Spectrum Analyzer Display43
- Front Panel Keys43
- Soft Key Types45
- Parameter Setting46
- Text Entry46
- Test Panel Connectors49
Chapter 3 - Vector Network Analyzer55
- Introduction55
- VNA First Time Use55
- Calibration57
- Using Trace Math62
  - Example62
  - Comparing Return Loss62
- Using Limit Lines64
  - Setting up Non-Segmented Limit Lines64
  - Setting up Segmented Limit Lines65
- VNA Measurements66
- VNA Key Functions79
Chapter 4 - Spectrum Analyzer114
- Making Spectrum Analyzer Measurements114
  - Selecting a Signal Standard115
- Resolution Bandwidth117
- Sweep Limitations118
- Field Measurements120
- Channel Power Measurement121
- GSM Channel Power Measurement122
- GSM Adjacent Channel Power Measurement123
- Out-Of-Band Spurious Emission Measurement124
- In-Band/Out-Of-Channel Measurements125
- In-Band Spurious Measurement126
- Field Strength128
  - Antenna Calculations129
- AM/FM/SSB Demodulation130
- Carrier to Interference Ratio Measurement131
- SPA Function Menu Tree134
- Amplitude135
- BW (Bandwidth)138
- File140
- Freq (Frequency)146
  - Limit149
- Marker155
- Measure159
  - Mode163
- Span164
- Sweep166
Chapter 13 - Master Software Tools169
- System169
- Trace173
Appendix D - Tower Mounted Amplifiers177
- Introduction177
Chapter 5 - Power Meter178
- Set the Limit Lines178
- Power Meter Mode Menus180
- Average Menu182
  - Freq (Frequency) Menu183
  - Limit Menu185
Appendix C - Windowing187
- Introduction187
Chapter 6 - Power Monitor, Option 5188
- Display Power in Dbm or in Watts188
  - Introduction191
  - Port Gain Measurements192
Chapter 7 - Built-In Bias Tee, Option 10194
- Bias Tee Menu194
  - Bias Tee Menu Soft Keys195
Appendix G - more about DHCP197
- Introduction197
Chapter 8 - Vector Voltmeter, Option 15198
- Using Vector Voltmeter Mode for the First Time198
- Simple Relative Measurements Using CW Display202
- Vector Voltmeter Measurements Using Table Display203
- Vector Voltmeter Mode Menus205
  - Table Menu207
  - Save/Recall Menu208
Appendix A - Signal Standards209
Appendix B - Error Messages209
- Introduction209
Chapter 9 - Interference Analyzer, Option 25212
- Signal Strength212
- RSSI (Received Signal Strength Indicator)214
- Freq (Frequency) Menu216
- Amplitude Menu219
- BW (Bandwidth) Menu221
- Measurements Menu223
- Spectrum Menu224
- Spectrogram Menu229
- Signal Strength Menu231
- RSSI (Received Signal Strength Indicator) Menu233
  - Marker Menu235
  - Introduction239
Chapter 10 - Channel Scanner, Option 27240
- Sample Channel Scanner Setup Procedure240
- Custom Setup241
  - Custom Setup Example242
- Scanner Menu243
  - Amplitude Menu245
- Custom Setup Menu246
  - Measurements Menu247
  - Introduction251
Chapter 11 - High Accuracy Power Meter252
- Getting Started with HAPM252
- HAPM Operation Procedure253
- Saving the Measurement255
- HAMP Menus256
  - Amplitude Menu257
  - Averages Menu259
Chapter 12 - GPS Receiver, Option 31264
- GPS Menu264
- GPS Info Window265
  - Almanac Complete266
Appendix E - Coaxial Cable Technical Data300
Appendix F - Formulas300
- Propagation300
- G-1 Introduction301
- Subnet Mask302
- Ping Tool303
