Anritsu MS2024A/MS2026A - Identifying the Models

1-2 Identifying the Models Chapter 1 — General Information
1-2 MS20xxA VNA Master UG 10580-00166 Rev. C
1-2 Identifying the Models
The MS202xA is differentiated from the MS203xA by the front panel model number label. In
addition, the MS203xA is larger and contains additional connections for spectrum analysis as
summarized in the following pictures and table.
Figure 1-1. MS2024A and MS2026A Connectors
MS2024A and MS2026A
RF In 50 Ohm
RF
Detector
RF Out/Reflection
50 Ohm
GPS
Antenna
Vector Network
Analyzer Connectors
10580-00166C.book Page 2 Thursday, February 21, 2008 12:52 PM
