Chapter 11 — High Accuracy Power Meter 11-3 HAPM Operation Procedure
MS20xxA VNA Master UG 10580-00166 Rev. C 11-5
Saving the Measurement
1. Press the Shift key, then the File (7) key.
2. Select the
Save soft key.
3. Press the
Save Measurement soft key and use the Text Entry soft keys to enter the desired
file name.
4. Press the
Save Screen as JPEG soft key to save an image of the screen as a JPEG. file.
Note
Screen captured images are provided as examples. The image and measurement
details shown on your instrument may differ from the examples in this user guide.
10580-00166C.book Page 5 Thursday, February 21, 2008 12:52 PM
