Scan Channels
Select scan channels to activate the scan channel menus:
Signal Standard
Sets the signal standard.
Channel #
Sets the starting channel on the display.
Number of Channels ##
Sets the number of channels to be displayed. From 1 to 20 channels can be
displayed.
Figure 10-1. Channel Scanner Mode Scanner Menu
Scanner
Scan
Channels
Scan
Frequencies
Scan
Custom List
-->
-->
-->
Recall
Measurement
Copy All
to
External Card
Delete
Copy All
from
External Card
-->
Channel Scan
Signal Standard
Channel
1
Channel Step Size
1
Number of Channels
10
Back
-->
Recall
Measurement
Copy All
to
External Card
Delete
Copy All
from
External Card
-->
Freq Scan
Start Freq
825.030 MHz
Freq Step Size
30.000 kHz
Number of Channels
10
Bandwidth
30.000 kHz
Back
-->
Recall
Measurement
Delete
-->
Custom Scan
Edit List
Number of Channels
10
Back
-->
