1-8 Standard and Optional Accessories
The standard accessories are slightly different depending upon whether the MS202xA or the
MS203xA has been purchased, as shown in the following table. These standard accessories
are supplied with the VNA Master:
The following optional accessories are available for the VNA Master:
Note Units with serial numbers below 0737000 sweep down to 100 kHz only.
Table 1-4. Standard Accessories
MS202xA
Part Number
MS203xA
Part Number
Description
10580-00166 10580-00166 User Guide
65729 65681 Soft Carrying Case
2300-498 2300-498 Master Software Tools CD ROM
633-44 633-44 Rechargeable Li-Ion Battery
40-168 40-168 AC-DC Adapter
806-141 806-141 Automotive Cigarette Lighter 12 VDC Adapter
3-2000-1498 3-2000-1498 Cable USB A/5-pin / Mini-B; 3 m (10 ft.)
2000-1371 2000-1371 Ethernet Cable 2.13 m (7 ft.)
3-2000-1500 3-2000-1500 256 MB Compact Flash Module
3-806-152 3-806-152 Ethernet Crossover Cable, 2.13 m (7 ft.)
2000-1520-R 2000-1520-R 2 GB USB Flash Drive
N/A 1091-27 N-m/SMA-f Adapter
N/A 1091-172 N-m/BNC-f Adapter
Table 1-5. Coaxial Calibration Components
Part Number Description
N Connector Components
OSLN50-1 Precision N(m) Open/Short/Load, 42 dB, 6 GHz
OSLNF50-1 Precision N(f) Open/Short/Load, 42 dB, 6 GHz
22N50 Precision N(m) Short/Open, 18 GHz
22NF50 Precision N(f) Short/Open, 18 GHz
SM/PL-1 Precision N(m) Load, 42 dB, 6.0 GHz
SM/PLNF-1 Precision N(f) Load, 42 dB, 6.0 GHz
TNC Connector Components
1091-53 Precision TNC(m) Open, 18 GHz, 50 Ω
1091-54 Precision TNC(m) Short, 18 GHz, 50 Ω
