Chapter 1 — General Information 1-8 Standard and Optional Accessories
MS20xxA VNA Master UG 10580-00166 Rev. C 1-7
1015-55 Precision TNC(m) Load, 18 GHz, 50 Ω
1091-55 Precision TNC(f) Open, 18 GHz, 50 Ω
1091-56 Precision TNC(f) Short, 18 GHz, 50 Ω
1015-54 Precision TNC(f) Load, 18 GHz, 50 Ω
Precision 3.5 mm Components
23L50 Precision 3.5 mm(m) Short, 9 GHz
23LF50 Precision 3.5 mm(f) Short, 9 GHz
24L50 Precision 3.5 mm(m) Open, 9 GHz
24LF50 Precision 3.5 mm(f) Open, 9 GHz
28L50R Precision 3.5 mm(m) Load, 9 GHz
28LF50R Precision 3.5 mm(f) Load, 9 GHz
Precision Open/Short/Load Components
2000-767 Precision Open/Short/Load, 7/16(m), 4.0 GHz
2000-768 Precision Open/Short/Load, 7/16(f), 4.0 GHz
Table 1-6. Precision Adapters
Part Number Description
34NN50A N(m)-N(m), DC to 18 GHz, 50 Ω
34NFNF50 N(f)-N(f), DC to 18 GHz, 50 Ω
Table 1-7. Adapters
Part Number Description
N to SMA Adapters
1091-26 N(m)-SMA(m), DC to 18 GHz, 50 Ω
1091-27 N(m)-SMA(f), DC to 18 GHz, 50 Ω
1091-80 N(f)-SMA(m), DC to 18 GHz, 50 Ω
1091-81 N(f)-SMA(f), DC to 18 GHz, 50 Ω
N Adapters
510-102 N(m)-N(m), 90º right angle, DC to 11 GHz, 50 Ω
DIN Adapters
510-90 7/16 DIN(f)-N(m), DC to 7.5 GHz, 50 Ω
510-91 7/16 DIN(f)-N(f), DC to 7.5 GHz, 50 Ω
Table 1-5. Coaxial Calibration Components (Continued)
Part Number Description
