1-8 Standard and Optional Accessories Chapter 1 — General Information
1-10 MS20xxA VNA Master UG 10580-00166 Rev. C
The Anritsu 560 Series Detectors use zero-biased Schottky diodes. The measurement range is
from –40 dBm to +20 dBm using single cycle per sweep AC detection, and uses auto-zeroing
with DC detection during the frequency sweep. Optional extender cables can be used with the
VNA Master with Option 5 installed. For additional detectors, refer to the Anritsu web
site, http://www.anritsu.com/.
Optional detector extender cables are useful for connecting a VNA Master and a Detector for
2-port measurements.
3-1010-122 Attenuator (Bi-directional), 20 dB, 5 Watt, DC to 12.4 GHz; N(m)-N(f)
3-1010-123 Attenuator (Bi-directional), 30 dB, 50 Watt, DC to 8.5 GHz; N(m)-N(f)
3-1010-124 Attenuator (Bi-directional), 40 dB, 100 Watt, DC to 8.5 GHz; N(m)-N(f)
Table 1-15. Miscellaneous Accessories
Part Number Description
633-44 Rechargeable Battery, Li-Ion
2000-1374 Dual External, Li-Ion Changer with Universal Power Supply
66864 Rack Mount (MS202xA only)
Table 1-16. 560 Series Detectors for use with Option 005
Model
Frequency
Range
Impedance Return Loss
Input
Connector
Frequency
Response
560-7N50B 0.01 to 20 GHz 50 Ω 15 dB, <0.04 GHz
22 dB, <8.00 GHz
17 dB, <18.0 GHz
14 dB, <20.0 GHz
N(m) ±0.5 dB, <18 GHz
±1.25dB, <20GHz
560-7S50B 0.01 to 20 GHz 50 Ω 15 dB, <0.04 GHz
22 dB, <8.00 GHz
17 dB, <18.0 GHz
14 dB, <20.0 GHz
WSMA (m) ±0.5 dB, <18 GHz
±2.0 dB, <20 GHz
Table 1-17. Detector Extender Cables
Part Number Description
800-109 7.6m (25 ft)
800-110 15.2m (50 ft)
800-111 30.5m (100 ft)
800-112 61.0m (200 ft)
Table 1-14. High Accuracy Power Sensor Accessories for use with Option 019 (Continued)
Part Number Description
