TD-LTE Signal Analyzer 6-12 Measurements Menu
3GPP MG PN: 10580-00234 Rev. T 6-45
Carrier Aggregation Menu
Key Sequence: Measurements > Over-the-Air > Carrier Aggregation
CC1 through CC5: Select the desired Component Carrier to set up for
measurement. See Figure 6-40.
Note: When switching from the Carrier Aggregation to other measurements,
the frequency is automatically set to the currently selected Component
Carrier, if it is on.
TAE: Time Alignment Error (TAE) is a measurement of the differential
transmission delay between the Component Carriers. The 3GPP
specification identifies the limits of the delays for the system to operate
properly.
Back: Returns to the “Over-the-Air Menu” on page 6-41.
Figure 6-39. Carrier Aggregation Menu
Carrier Aggregation
CC1
CC2
CC3
Back
CC5
CC4
TAE
Off On
