CPS100 SERIES OPERATION MANUAL
SECTION 6:
Front Panel Operation
Entire Contents Copyright 2018 by Adaptive Power Systems, Inc. (APS) • All Rights Reserved • No reproduction without written authorization from APS.
APS CPS100 Series Power Source Operation Manual Page 128 of 231
IEC 4-13 Inter-harmonics Test
From the top level IEC 4-13 menu, press the
Inter-harmonics soft key to display the Inter-
harmonics test screen.
Available soft keys in this screen are Trigger
and Edit. Press the Edit soft key to set the
required test selections for this test.
There are two standard product classes for
the IEC 61000-4-13. They are Class 2 and
Class 3. (Standard modes) Test levels and
durations for these product classes are
defined by the IEC 61000-4-13 standard.
There is also a User class, which allows
parameters to be changed. (User mode).
To select the appropriate product class for
the unit under test, move the cursor to the
“Level =” field and press [Enter]. A drop
down list with product class selections is
displayed.
