EFD1000 PFD Pilot’s Guide
CHAPTER 5, CUSTOMIZING THE EFD1000 PFD
EFD1000 PFD Pilot’s Guide
EFD1000 PFD Pilot’s Guide Page 5-7A-01-184-00 REV B
LEVEL DISPLAY DESCRIPTION
OFF
Fixed
Figure 5-12 No Map
No symbols, legs, or waypoints - regardless of selected range - are
displayed. When selected, the map symbol level and range icons
display for two seconds and then are removed from view. The MAP
Hot Key legend displays in gray (Figure 5-17).
Range (NM) 2.5 5 10 15 20 30 40 60 80 100 200
HIGH
Variable
Figure 5-13 High Map
Waypoints D* D* D* D* D* D* D* D D D D
Airports D* D* D* D* D* D D D D D
NDBs D* D* D* D D D D
VOR/DME - High D* D* D* D D D D D D D D
VOR/DME - Low D* D* D* D D D D
VOR/DME - Terminal D* D* D* D D D
Intersections D* D* D* D
MEDIUM
Variable
Figure 5-14 Medium Map
Flight Plan Waypoints D* D* D* D* D* D* D* D D D D
Airports D* D* D* D* D* D D D D D
VOR/DME - High D* D* D* D D D D D D D D
VOR/DME - High D* D* D* D D D D
LOW
Variable
Figure 5-15 Low Map
Flight Plan Waypoints D* D* D* D* D D D D D D D
Airports D* D* D* D* D* D D D D D
VOR/DME - High D* D* D* D D D D D
FP ONLY
Fixed
Figure 5-16 Flight Plan Only Map
Only Flight Plan Waypoints display.
D – symbol displayed
D* - symbol displayed with identier
Figure 5-17
Basemap “OFF” Hot Key Legend
Table 5-8
Map Display Levels
