Aspen Avionics Evolution EFD1000 PFD - Select the Single-Line Bearing Pointer Source; Select the Double-Line Bearing Pointer Source

EFD1000 PFD Pilot’s Guide
CHAPTER 4, REFERENCE GUIDE
EFD1000 PFD Pilot’s Guide
EFD1000 PFD Pilot’s Guide Page 4-33A-01-184-00 REV B
Select The Single-Line Bearing Pointer Source
Press the Single-Line Bearing Pointer button (lower left button, • Figure 4-73)
until the desired navigation source displays above the Single-Line Bearing
Pointer button.
Select The Double-Line Bearing Pointer Source
Press the Double-Line Bearing Pointer button (lower right button, •
Figure 4-74) until the desired navigation source displays above the Double-
Line Bearing Pointer button.
Figure 4-73 173
Single-Line Bearing Pointer and Button
Figure 4-74
Double-Line Bearing Pointer and Button
