EFD1000 PFD Pilot’s Guide
CHAPTER 3, FLYING THE EFD1000 PRO PFD
EFD1000 PFD Pilot’s Guide
EFD1000 PFD Pilot’s Guide Page 3-13A-01-184-00 REV B
Our normal climb speed is 120 KIAS, so we choose to set the airspeed bug as a
reminder. To do so, we press the Left Control Knob twice, until it shows IAS in magenta
above the knob. We turn the knob until 120 shows in the Selected Airspeed Field.
Set the Airspeed Bug
1. Press the Left Knob until IAS displays above the Left Knob and the Selected
Airspeed eld and bug are enabled for editing, all three rendered in magenta
(Figures 3-21 and 3-22).
2. Rotate the Left Knob to change the value of the Selected Airspeed eld.
Rotate clockwise to increase, or counterclockwise to decrease, the value.
Once the correct value is selected and after 10 seconds of inaction, the eld is
disabled and the label and eld are rendered in cyan (Figure 3-23).
Figure 3-21
Selected Airspeed Field Enabled
Figure 3-23
Selected Airspeed Field Disabled
Figure 3-22
Selected Airspeed Bug Enabled
NOTE
Synchronizing the airspeed sets
the selected airspeed to the current
airspeed, see Section 4.1.2.2.
