Chapter 2
Controls and Display
The EFD1000 Pro PFD is a at-panel LCD primary ight instrument that
presents the pilot on a single display with all the information delivered
by the traditional six-pack of mechanical instruments: Airspeed, Attitude,
Altitude, Turn Coordinator, Heading Indicator (or HSI) and Vertical Speed
Indicator (VSI). Modern technology and standard EFIS symbology
enable the consolidation of all six instruments into a single display,
tightening the pilot’s instrument scan and reducing pilot workload.
The Pro PFD is a single vertical instrument that replaces the existing Attitude Indicator
and Heading Indicator/HSI. The display is divided into three parts: an upper Attitude
Display, a lower Navigation Display, and a Data Bar in the middle of the upper and lower
halves. The Attitude and Navigation displays are highly customizable — from stripped-
down, minimalist presentations, to dense, information-rich displays — depending on
pilot preference and phase of ight.
This Chapter gives an overview of all the instruments, information, and controls of the
EFD1000 Pro PFD. The next two pages show and identify each element of the display
and each control with a Reference (Ref.) number and description. Throughout this
section, notes like “(Ref. 27)” refer to Table 2-1 and Figure 2-2. For more detailed
information on any specic part, see the Reference Guide, Chapter 4.
