7.3.2. Remote Sensor Module (RSM)
Part Number A-05-111-00
Width 2.65 in.
Length 4.40 in
Height 1.00 in.
Weight 0.2 lbs
Input Voltage Provided by EFD1000
Max Current Included in EFD1000 Current
Table 7-3 Remote Sensor Module (RSM) Specications
7.3.3. Analog Converter Unit (ACU)
Part Number A-05-112-00
Width 5.75 in. (including mounting ange)
Length 4.30 in. (including connector)
Height 1.60 in. (including mounting ange)
Weight 0.8 lbs
Input Voltage +10 to +32 Volts DC
Max Current 0.5 Amps @ 28 Vdc
1.0 Amps @ 14 Vdc
Interfaces ARINC-429 and RS-232
Table 7-4 Analog Converter Unit (ACU) Specications
