CHAPTER 2, CONTROLS AND DISPLAY
EFD1000 PFD Pilot’s Guide
Page 2-2 A-01-184-00 REV B
EFD1000 PFD Pilot’s Guide
EFD1000 PFD Pilot’s Guide
2.1. Controls & Display Orientation
ATTITUDE DISPLAY
16 Attitude Display
17 Aircraft Symbol
18 Single-Cue Flight Director (optional)
19 Roll Pointer
20 Slip/Skid Indicator
21 Altitude Tape
22 Selected Altitude Field
23 Altitude Alert
24 Altitude Drum/Pointer
25 Altitude Bug
26 Decision Height Annunciation
27 Selected Minimums Field
28 MINIMUMS annunication
29 LDI Navigation Source Indication
30 Airspeed Indicator Tape
31 Selected Airspeed Field
32 Airspeed Bug
33 Airspeed Drum/Pointer
34 Vertical Deviation Indicator
35 Lateral Deviation Indicator
Figure 2-1 EFD1000 Actual Display
CONTROLS
1 Reversion and Power Control
2 Range Control
3 Menu Control
4 TPS Hot Key - Tapes On/O
5 MIN Hot Key - Minimums On/O
6 360/ARC Hot Key - HSI View
7 MAP Hot Key - Map Declutter Logic
8 GPSS Hot Key - GPS Steering On/O
9 Right Control Knob
10 Double-Line Bearing Pointer Source
Select
11 CDI Source Select
12 Single-Line Bearing Pointer Source Select
13 Left Control Knob
14 Automatic Dimming Photocell
15 Micro SD Card Slot
