2.3.3. Navigation Display
The lower half of the EFD1000 PFD is the Navigation Display, which shows a wide range
of navigation information and ight data, including (Figure 2-35):
Horizontal Situation Indicator (HSI), with Course Pointer and Deviation •
Indicator (CDI), and Heading Bug, oering both 360º and ARC mode views.
Digital readouts of current magnetic heading, selected heading (HDG), and •
selected course (CRS).
Information about the currently selected navigation source, or active GPS •
waypoint.
Ground Track indicator.•
Vertical Speed Indicator (VSI) tape and digital rate value.•
Rate of Turn indicator.•
Dual bearing pointers (RMI).•
Situational awareness Map display.•
Identication of the navigation sources to which the Course Deviation •
Indicator (CDI) and two bearing pointers are currently coupled.
GPS Annunciations (TERM, APPR, WPT and MSG).•
Caution annunciations for abnormal GPS status.•
When connected to a GPS navigator, basic mapping can also be displayed under the
HSI display, including GPS ight plan legs and waypoints, and (when connected to a
compatible GPS) nearby navigation data (airports, VORs, NDBs and intersections).
NOTE
The Vertical Deviation Indicator
(VDI) and Lateral Deviation Indicator
(LDI) are part of the navigation
instruments but display on the
Attitude Display.
