4.1.3.4. MINIMUMS Alert
The EFD1000 PFD provides an adjustable MINIMUMS eld to enhance situational
awareness during instrument approaches. Once the MIN data eld value is set to a
Decision Height or Minimum Descent Altitude, the EFD1000 PFD provides an alert
when the aircraft descends below this altitude. To activate this feature, the pilot must
enable the MINIMUMS display and set the desired altitude via MIN data eld value
adjustment.
Display/Hide Minimums
Press the MIN Hot Key to alternately hide or display the MINIMUMS display •
(Figures 4-22 and 4-23).
NOTE
Pressing the MIN Hot Key turns on
the MINIMUMS display and enables
the MIN data eld for editing. The
MIN label displays above the Right
Knob in Magenta and the MIN data
eld’s numerical value is also rendered
in Magenta. See Step 2 of Set
Altitude Minimum.
Figure 4-22
MIN Hot Key – Selected
Minimums Disabled
Figure 4-23
Selected Minimums Enabled
