EFD1000 PFD Pilot’s Guide
Page 7-6 A-01-184-00 REV B
CHAPTER 7, APPENDICES
EFD1000 PFD Pilot’s Guide
EFD1000 PFD Pilot’s Guide
Max Humidity 95% at 50°C
Input Voltage +8 to +32 Volts DC
Max Current 2.4 Amps @ 28 Vdc
4.8 Amps @ 14 Vdc
I/O SPECIFICATIONS:
ARINC 429 Inputs 5 Low Speed
ARINC 429 Outputs 1 Low Speed
RS-232 Inputs 5
RS-232 Outputs 3
Pitot / Static Quick Connect
CERTIFICATION SPECIFICATIONS:
Technical Standard Order TSO-C2d Airspeed Instruments
TSO-C3d Turn and Slip Instrument
TSO-C4c Bank and Pitch Instruments
TSO-C6d Direction Instrument Magnetic
(Gyroscopically Stabilized)
TSO-C8d Vertical Velocity Instrument
(Rate of Climb)
TSO-C10b Altitude Pressure Activated Sensitive
Type
TSO-C106 Air Data Computer
TSO-C113 Airborne Multipurpose Electronic
Displays
Software RTCA DO-178B Level C
Environmental RTCA DO-160E
Categories See Environmental Qualication Sheet
Table 7-2 EFD1000 Display Unit Specications
